Frame
Alpha Smooth Aluminium, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
Fork
SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Max compatible fork travel
50 mm
Hub front
Shimano TX505, CenterLock
Hub rear
Shimano FH-QC300-HM, 32-hole, CentreLock, 8-/9-/10-/11-speed, 135x5 mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre
Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
Max tyre size
700x50 mm with or without mudguards
Charger
Bosch standard 4A, 230V, smart system
Controller
Bosch Intuvia 100, smart system
Computer
Bosch LED remote, smart system
Motor
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Shifter
Shimano Altus M2010, 9-speed
Rear derailleur
Shimano Altus M2000, long cage
*Crank
Size: XS, S, MProWheel alloy, 170 mm lengthSize: L, XLProWheel alloy, 175 mm length
Chainring
ProWheel 38T narrow/wide steel, w/alloy guard
Cassette
Shimano HG200, 11-36, 9-speed
Chain
KMC E9S, 9-speed
Pedal
slip-proof pedals with reflectors
Saddle
Selle Royal Nuvola
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
Handlebar
Bontrager aluminium touring
Grips
Herrmans Clik, ergonomic, lock-on
*Stem
Size: XS, S, MBontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm lengthSize: L, XLBontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake
Tektro HD-M275 hydraulic disc
*Brake rotor
Size: XS, S, M, L, XLShimano EM300, CenterLock, 160 mmSize: XS, S, M, L, XLShimano RT10, CenterLock, 160 mm
Brake Set
Tektro HD-M275 hydraulic disc
*Light
Size: XS, S, M, L, XLSpanninga SOLO for e-bikeSize: XS, S, M, L, XLHerrmans MR4, 120-lumen LED
Kickstand
Pletscher Comp Flex 18
Cargo rack
Alloy rear rack, 25 kg max weight
*Mudguard
Size: XS, S, M, L, XLSKS plastic, frontSize: XS, S, M, L, XLSKS plastic, rear
Weight
M – 27.80 kg (with 545 Wh battery)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
