Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount. 135x5 mm QR
Fork
Dual Sport alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyre
Bontrager GR0 Comp, wire bead, 60 tpi, 650x50 c
Max tyre size
27.5x2.0"
Shifter
Shimano Altus M2010, 9-speed
Front derailleur
Shimano Acera T3000, 34.9 mm clamp, top swing, dual pull
Rear derailleur
Shimano Altus M2000, long cage
Crank
Forged alloy, 46/30, chainguard, 170 mm length
Bottom bracket
Sealed cartridge, 68 mm
Cassette
Shimano HG200, 11-36, 9-speed
Chain
KMC X9
Pedal
Wellgo nylon body, alloy cage
Max. chainring size
1x: 42T, 2x/3x: 48T
Saddle
Bontrager Sport
Seatpost
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: M
Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Size: L, XL
Bontrager alloy, 31.8 mm, 15 mm rise, 690 mm width
Grips
Bontrager Satellite
Stem
Size: S
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size: M, L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Brake Set
C-Star BH-RS925T hydraulic disc, 160 mm rotor
Rotor size
Max brake rotor size: 160 mm
Weight
M - 12.79 kg / 28.2 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
