Frame
Alpha Gold Aluminium, internal cable routing, internal battery, rack and mudguard mounts, flat-mount disc, kickstand mount, 144.5 mm OLD hub motor spacing
Fork
DS+ alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm bolt-on skewer
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear
HyDrive hub drive motor, 40 Nm, 250 W
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre
Bontrager GR0 Comp, wire bead, 60 tpi, 650x50 c
Max tyre size
27.5x2.0" with or without mudguards
Shifter
Shimano Altus M2010, 9-speed
Rear derailleur
Shimano Altus M2000, long cage
Crank
Size: S, M
ProWheel Pro alloy, 42T narrow-wide steel ring, 170 mm length
Size: L, XL
ProWheel Pro alloy, 42T narrow-wide steel ring, 175 mm length
Bottom bracket
Torque sensor, threaded, 122.5 mm spindle
Cassette
Size: S
Shimano Deore M4100, 11-46, 10-speed
Size: M, L, XL
Shimano HG200, 11-36, 9-speed
Chain
KMC E9S, 9-speed
Max. chainring size
42T
Saddle
Bontrager Sport
Seatpost
Size: S, M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: L, XL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: S, M
Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Size: L, XL
Bontrager alloy, 31.8 mm, 15 mm rise, 690 mm width
Grips
Size: S
Bontrager XR Endurance Comp
Size: M, L, XL
Bontrager XR Endurance Comp, lock-on
Stem
Size: S
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size: M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Size: L, XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Brake
Shimano hydraulic disc, MT200 lever, UR300 calliper
Brake rotor
Shimano RT26, 6-bolt,160 mm
Brake Set
Promax DSK-927 hydraulic disc, flat mount, 160 mm rotor
Battery
250 Wh
Controller
Bluetooth display
Light
Size: S, M, L, XL
Herrmans MR4, 120-lumen LED
Size: S, M, L, XL
Spanninga Solo
Kickstand
Pletscher Comp 18
Weight
M - 17.41 kg / 38.39 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
