Frame
500 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, flat-mount disc, Duo Trap S-compatible, 142x12 mm thru-axle
Fork
Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat-mount disc, carbon dropouts, 12x100 mm thru axle
Frame fit
H1.5 Race
Wheel front
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
Wheel rear
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, SRAM XD-R driver, 142x12mm thru axle
Skewer front
Bontrager Switch thru axle, removable lever
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
Tyre
Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25 c
Max tyre size
28c
Shifter
SRAM Force eTap AXS, 12-speed
Front derailleur
SRAM Force eTap AXS, braze-on
Rear derailleur
SRAM Force eTap AXS, 36T max cog
Size:50, 52
SRAM Force AXS Power Meter, 48/35, DUB, 170mm length
Size:54, 56
SRAM Force AXS Power Meter, 48/35, DUB, 172.5mm length
Size:58, 60, 62
SRAM Force AXS Power Meter, 48/35, DUB, 175mm length
Bottom bracket
SRAM DUB, T47 threaded, internal bearing
Cassette
SRAM Force XG-1270, 10-33, 12-speed
Chain
SRAM Force, 12-speed
Max. chainring size
1x: 50T, 2x: 54/40
Saddle
Bontrager Aeolus Comp, steel rails, 145 mm width
Size:50, 52, 54, 56
Madone aero carbon internal seat mast cap, integrated light mount, 5 mm offset, short length
Size:58, 60, 62
Madone aero carbon internal seat mast cap, integrated light mount, 5 mm offset, tall length
Size:50, 52
Bontrager Elite Aero VR-CF, alloy, 31.8 mm, invisible cable routing, 93 mm reach, 123 mm drop, 40 cm width
Size:54, 56
Bontrager Elite Aero VR-CF, alloy, 31.8 mm, invisible cable routing, 93 mm reach, 123 mm drop, 42 cm width
Size:58, 60, 62
Bontrager Elite Aero VR-CF, alloy, 31.8 mm, invisible cable routing, 93 mm reach, 123 mm drop, 44 cm width
Handlebar tape
Bontrager Supertack Perf tape
Size:50
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size:52, 54
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size:56, 58
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size:60, 62
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Brake rotor
SRAM CenterLine X, CenterLock, round edge, 160 mm
Rotor size
Max brake rotor sizes: 160 mm front and rear
Battery
SRAM eTap battery pack (with charger)
Weight
56 - 8.48 kg / 18.71 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
